Configuration
|
•65" LED panel With Ultra HD 4k resolution
•Quad Core CPU; 4GB RAM, 16GB ROM
•Frameless Bezel Design
•Content apps and Google Play
|
Specification
|
Model |
XPN-DSA6560 |
|
Operating System |
Android TV with Google Play |
|
Preinstalled Apps |
Google Play, Google Assistant, Youtube, Netflix, etc. |
|
Panel size/Display |
65″Wide – Dolby Vision |
|
Aspect ratio |
16:9 |
|
Viewing angle |
H:178°/V:178° |
|
Max.resolution |
3840*2160 Ultra HD Resolution |
|
Display color |
1.07b |
|
Max. brightness |
Typ:250cd/m2 |
|
Max. contrast ratio |
4000：1 ; Dynamic contrast ratio |
|
HDR |
HDR10 |
|
Response time |
6ms |
|
Input signal |
3 x HDMI 2.1 (HDCP 2.2); 2x 2.0 USB Ports, 1x 3.0 USB Port, RF In, AV In (Mini AV-In), RJ45 Port (Ethernet) HDMI-ARC, HDMI-CEC |
|
Output Signal |
Coaxial-OUT/SPDIF Out Optical |
|
CPU |
ARM Cortex-A55 ; Mali-G52 MP2 GPU ; 4GB DDR3 RAM, 16GB Storage |
|
Power consumption |
≤160W |
|
Operating voltage |
Auto volt, Auto sensing frequency. 100-240V a.c. 50/60Hz |
|
Audio Power output |
2.0 Channel (10W×2) Dolby Audio |
|
Bluetooth |
Bluetooth 5.0 |
|
Wireless |
Wi-Fi AC Connectivity: Support dual band - 2.4Ghz/5Ghz Wireless 2T2R. |
|
USB |
Support:Video/Audio/Image |
|
Size L×W×H |
Size (carton) L×W×H 1588x152x938mm; 19.8kg Size (with stand) L×W×H 1445x350x886mm; 15kg Size (Wall Mount Hole) 300*200mm |
|
Working Environment |
Temperature：5℃～40℃ humidity：20%～80% atmosphere：86KPa～106KPa |
|
Storage Environment |
Temperature：-20℃～55℃ humidity：20%～80% atmosphere：86kPa～106kPa |
|
Warranty |
3 Years Warranty on Parts and Labor |
